Details
HAUL ASS, NOT CARGO
In 2019, Áspero took the gravel world by storm, heralding a “new era of speed in gravel.” Fun, but flat out. The new Áspero remains true to its original brief, but with some improvements: a threaded BB shell, neater cable routing, and a UDH-compatible derailleur hanger for those who want to use SRAM’s Transmission drivetrains. And it’s more aero, of course. In the case of Áspero, aerodynamic performance is less about pure speed as a result of drag reduction, and more about conservation of energy. After a big day in a headwind, the three watts saved over the previous Aspero might add up to one less energy gel your stomach has to digest—WORTH IT.
In addition to the drag reduction, we also dropped the seat stays to give a bit more compliance out back, and reduced front-end stiffness slightly to make the last hours of a long race less painful. Between those dropped seat stays, we added in a bit more clearance for mud, too, taking what we learned from R5-CX (and the Unbound mudfest in 2023). It’s a lot of seemingly small improvements, but they add up to a lot. The result is a bike that feels a lot like the original Áspero, but is faster, more comfortable, and more versatile.
THREADED BOTTOM BRACKET
Aspero uses the asymmetrical T47a threaded bottom bracket we pioneered on R5-CX. It’s a simple, rider-serviceable interface that allows us to deliver the benefits of BBRight in a more user-friendly form.
UNIVERSAL DERAILLEUR HANGAR
We used SRAM’s Universal Derailleur Hanger (UDH) standard on the new Aspero. It’s ideal if you want to live your best ‘business in the front, party in the back’ life with one of SRAM’s Transmission drivetrains today, and ensures compatibility for future drivetrain developments.
INTERNAL CABLE ROUTING
Aspero shares the same bearing dimensions as R5, Soloist, R5-CX, and Caledonia, which means you can use any combination of bearing caps and stems. Want a super-racy, fully-internal look? Grab the ST31 and HB13 from R5.
48 | 51 | 54 | 56 | 58 | 61 | |
---|---|---|---|---|---|---|
Reach | mm | 370 | 379 | 388 | 397 | 406 | 415 |
Stack | mm | 505 | 530 | 555 | 580 | 605 | 630 |
Head Tube Angle | 71° | 71.5° | 72° | 72° | 72° | 72° |
Front Center | mm | 577/582 | 587/592 | 597/602 | 614/619 | 631/637 | 648/654 |
Bottom Bracket Drop | mm | 78.5 | 78.5 | 76 | 76 | 73.5 | 73.5 |
Head Tube Length | mm | 83 | 107 | 133 | 159 | 188 | 214 |
Top Tube Length | mm | 512 | 532 | 553 | 575 | 591 | 608 |
Seat Tube Angle | 74.5° | 74° | 73.5° | 73° | 73° | 73° |
Standover Height | mm | 681 | 704 | 733 | 757 | 784 | 808 |
Trail | mm | ||||||
Wheel Size | 700C | 700C | 700C | 700C | 700C | 700C |
Fork Offset | mm | 52/57 | 49/54 | 46/51 | 46/51 | 46/51 | 46/51 |
Wheelbase | mm | 990/995 | 999/1004 | 1010/1015 | 1028/1033 | 1046/1051 | 1063/1068 |
Chainstay Length | mm | 425 | 425 | 425 | 425 | 425 | 425 |
Specs
Fork | Cervélo All-Carbon, Tapered Aspero Fork |
---|---|
Stem | Cervélo ST36 Alloy, w Cable Management |
Chain | Shimano M8100, 12 speed |
Tires | WTB Vulpine TCS Light Fast Rolling Dual DNA 60tpi 700x40c |
Brakes | Shimano GRX RX820 |
Rotors | Shimano CL800 Centerlock |
Saddle | Prologo Dimension NDR T4.0 |
Wheels | Fulcrum Rapid Red 300, 12x100(F)/142(R), 24H, 24mm IW, HG freehub, centerlock, tubeless compatible |
Headset | FSA IS2 1-1/4 x 1-1/2 |
Crankset | Shimano GRX 820, 48/31T, 12 Speed |
Seatpost | Cervélo SP19 Carbon 27.2 |
Handlebars | Cervélo AB09 Carbon, 31.8mm clamp, 16 degree flare |
Bottom Bracket | FSA, T47 BBright, 24mm spindle |
Rear Derailleur | Shimano GRX, RX820, 12 speed |
Front Derailleur | Shimano GRX, RX820, 12 speed |
Accessories & Extras | Smartpak 400A Top Tube Storage Bag |
Cassette/Freewheel | Shimano HG710, 11-36, 12 speed |
Shifters | Shimano GRX, RX820, 12 speed |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN | Store SKU |
---|---|---|---|
Sea Ice / 51cm / 700c | 42677658580 | 0J0ASBG82A51 | 210000023375 |
Sea Ice / 48cm / 700c | 42677658573 | 0J0ASBG82A48 | |
Woodsmoke / 54cm / 700c | 42677658535 | 0J0ASBG81A54 | |
Sea Ice / 61cm / 700c | 42677658627 | 0J0ASBG82A61 | |
Sea Ice / 56cm / 700c | 42677658603 | 0J0ASBG82A56 | 210000023830 |
Woodsmoke / 58cm / 700c | 42677658559 | 0J0ASBG81A58 | |
Woodsmoke / 51cm / 700c | 42677658528 | 0J0ASBG81A51 | 210000023883 |
Sea Ice / 58cm / 700c | 42677658610 | 0J0ASBG82A58 | |
Woodsmoke / 61cm / 700c | 42677658566 | 0J0ASBG81A61 | |
Sea Ice / 54cm / 700c | 42677658597 | 0J0ASBG82A54 | 210000023585 |
Woodsmoke / 56cm / 700c | 42677658542 | 0J0ASBG81A56 | |
Woodsmoke / 48cm / 700c | 42677658511 | 0J0ASBG81A48 |
